Spiraltec and Technical University of Munich Discuss Future Areas of Collaboration
As part of a joint meeting, engineers from Spiraltec and the Technical University of Munich (TUM) came together to exchange ideas on current developments, technological challenges, and potential areas of collaboration. The focus was on strengthening the exchange between research and industry, as well as identifying fields where both sides can contribute their expertise and work together on future-oriented solutions.
Spiraltec values the constructive dialogue and the valuable impulses gained from this exchange. Collaboration with research institutions such as the Technical University of Munich plays an important role in driving innovation, continuously improving existing technologies, and developing sustainable solutions for complex industrial processes.
Introducing the New DDP Compact System Line: Fully Automatic Diffusion Dialysis, Built to Scale
Building on the unique technology of diffusion dialyses, we're proud to launch our new generation of compact systems, the DDP4 and DDP11 — fully automatic units designed for efficient treatment of process solutions in metal finishing, surface treatment, and a wide range of other applications for free acid/alkali recovery. The DDP11 is built for higher-volume applications, accommodating up to eleven membrane spiral-wound modules with a pump output of up to 220 l/h, an operating pressure of up to 2.5 bar, and integrated feed tanks (3 × 35 l + 1 × 100 l) — all within a footprint of 1970 × 1000 × 1650 mm and an empty weight of approx. 440 kg. The more compact DDP4 offers the same automation and reliability for smaller throughput needs, housing four modules with a pump capacity of up to 120 l/h, individual 35 l feed tanks per module, and a footprint of 1600 × 820 × 1700 mm at roughly 300 kg. Both systems run on a standard 230 V single-phase supply and feature integrated safety filtration and flexibly adjustable volume flows out of the box.
At the core of both systems is our spiral-wound membrane diffusion dialysis technology, which delivers very low energy consumption and the highest separation efficiency for metal salts — while minimizing neutralization and wastewater treatment costs, and keeping maintenance requirements low. Whether you need the throughput of the DDP11 or the compact flexibility of the DDP4, our new product line makes high-performance diffusion dialysis accessible for a broader range of applications.
(Diffusion dialysis is a membrane separation process used to recover free acids and bases from electrolytic solutions, or to selectively exchange ions within them — and Spiraltec GmbH is the only company in the world offering spiral-wound membrane modules suitable for countercurrent flow operation, the configuration that delivers the process's highest efficiency.)
Visit of the Minister of Economic Affairs Dr. Hoffmeister-Kraut
On 25.01.2024, the Managing Director and owner of Spiraltec GmbH, Mr. Holger P. Härter, welcomed the Minister of Economic Affairs of Baden-Württemberg, Dr. Nicole Hoffmeister-Kraut, to Spiraltec GmbH to discuss the political framework conditions and the future of technological innovations in Baden-Württemberg.
Online Webinar 2024
We are excited to share our recently recorded international webinar, hosted by SPIRALTEC GMBH, a pioneer in industrial wastewater treatment and recycling technologies. Dive into the latest advancements and solutions we offer by accessing our webinar now.
Webinar Title:
Sustainable Technologies For Industrial Wastewater Treatment and Recycling
This webinar aims to provide an in-depth look into cutting-edge technologies for industrial wastewater treatment and recycling, focusing on Diffusion Dialysis Technology for Acid and Base Recovery and Spiral-Electrocoagulation (S-EC). The discussions will be led by esteemed experts in the field, Dr.-Ing. Thomas Weimer and Dr.-Ing. Ehsan Jafari.
Webinar held on:
24th January 2024 at 8:00 AM (UTC)
We invite you to access our recorded webinar. Dive into the session at your convenience by following the link below to our webinar archive:
We look forward to the opportunity to connect and share valuable insights.
Best regards,
Holger P. Härter
Managing Director and Owner
Diffusion dialysis for recovery of bases
After a long development of membrane spiral membrane modules for the recovery of bases, the first pilot plant with 20 modules was successfully delivered to customers.
Finally international trade fairs again
We look forward to starting this year's trade fair season with the Korea Surtech exhibition 2022. After two years of rest, we look forward to making new contacts and expanding our market worldwide.
4th place in the innovation award "The Surface".
The Stuttgart surface technology prize "Die Oberfläche" is awarded by Fraunhofer IPA. The award honors the most innovative applications and technologies within all disciplines of surface technology. Particularly noteworthy are innovations that are referred as "enablers" - those without the introduction of certain products or technologies would not be possible. In addition to the degree of innovation, the award distinguishes the energy efficiency, sustainability, maintaining competitiveness and the industrial feasibility of the application or technology. Here, all disciplines of surface technology are taken into account. Spiraltec GmbH took 4th place in this year's competition for the development of its spiral membrane modules: An optimized technology, using wound membrane modules, for the separation of metal salts and acids.
Spiraltec GmbH applies for patent for wound redox flow battery
Spiraltec GmbH is the first company in the world to apply for a patent to develop a wound cylindrical geometry for a redox flow battery. The aim is to adapt the cost benefits that were achieved by Spiraltec GmbH in the development of spiral membrane modules for diffusion dialysis to the redox flow battery and thus develop economically attractive high-performance batteries for a wide range of applications.
Spiraltec donates disinfectants to refugee camps
In order to further reduce the spread of Covid-19, highly effective disinfectants are required. It was obvious for Spiraltec GmbH to support the appeal for funds for refugees in anchor centers. Therefore, Spiraltec GmbH donated a large amount of its highly effective and environmentally friendly disinfectant to the office of Dr. Pierrette Herzberger-Fofana, Member of the European Parliament. We are looking forward to be a competent long-term partner for Dr. Pierrette Herzberger-Fofana and her team.
Spiraltec sells environmentally friendly disinfectants
The companies FUMATECH BWT GmbH and HPH Beteiligungsgesellschaft synergized to place an environmentally friendly, highly effective water-based disinfectant on the market.
For more information please write an email to This email address is being protected from spambots. You need JavaScript enabled to view it.
New application for spiral membrane modules: Selective ion exchange
Spiraltec’s Spiral Membrane Modules have been tested for selective ion substitution. The substitution of Chloride by Sulfate Ions was demonstrated successfully in lab and industrial field test since the beginning of 2019. This means that from now on Diffusion Dialysis with Spiral Membrane Modules can simplify the recovery of metals by electrolysis as a upstream process.
Full automatic small system for 15 l / h bathcare - Galvanotechnik 12/19
The smallest System DDP1 offers smaller surface finishers finally the possibility of an environmentally friendly and operating cost-saving system for bathcare.
New spiral membrane modules expand field of applications
In addition to the standard WD-AR10-1001 module, Spiraltec also offers two more spiral modules with increased chemical resistance. Spiraltec expand their field of applications for its environmentally friendly diffusion dialysis. The recovery of higher sulfuric acid concentration and higher hydrochloric acid concentration up to a maximum of 10% is possible now.
Exhibitor at the Aquatech in Amsterdam
04.11.2019 to 08.11.2019 the Aquatech Fair takes place in Amsterdam. Spiraltec is pleased to be a guest at the booth of our distribution partner Mega. At the leading trade fair for process-, drinking- and wastewater you find us in hall 1 booth 103.
MEGA takes over distribution for Spiraltec in Eastern Europe, the Baltic States and the CIS
The company MEGA and its subsidiary MemBrain take over the exclusive distribution rights for Eastern Europe, the Baltic States and the CIS countries.
Holger P. Härter, owner and managing director of Spiraltec: "Our modules are economically highly attractive for industrial users in surface technology and at the same time protect the environment sustainably. With the MEGA Group, we now have the right partner to be able to offer our innovative product to even more customers".
FUMATECH BWT and Spiraltec expand strategic partnership.
Innovative spiral membrane modules are jointly distributed throughout Europe
FUMATECH BWT GmbH, Bietigheim-Bissingen, and Spiraltec GmbH, Sachsenheim, are expanding their successful development cooperation in industrial applications for flat membrane films to include a comprehensive sales cooperation in the Western European market in order to establish close coordination in the project planning of major projects in plant construction.
Compact module expands product range.
The DS10 absorbs up to 10 membrane spiral modules.
The optimal design allows the user to individually, application-oriented and cost-optimized assembly of the PP10 of one up to ten spiral modules.
Simple parallel connections of multiple modules, easy handling of the individual spirales, and a compact, stackable design make the module the ideal solution for larger applications.
certified quality management
Spiraltec GmbH has been awarded certification under the current standard ISO 9001: 2015 in 2019.
Spiraltec guarantees its customers and suppliers an efficient and reliable cooperation thanks to the implementation of ISO 9001: 2015 quality management.
New member of ZVO
Spiraltec GmbH is a member of the Zentralverband für Oberflächentechnik e.V. since January 01, 2019.
Zentralverband Oberflächentechnik eV (ZVO) represents the interests of contract manufacturers from industry and trade, in-house coaters, raw and process suppliers, equipment manufacturers, component manufacturers and service providers of German electroplating and surface technology.
